Equipment Skids & Base Frames

Equipment Skids and Base Frames are engineered structural platforms designed to support HVAC and process equipment safely, maintain alignment, absorb operational loads, and ensure long-term structural stability. They are commonly used for chillers, pumps, cooling towers, AHUs, heat exchangers, compressors, and utility equipment packages.

We fabricate standard structural steel base frames (channel frame, I-beam fabricated, cross-braced), heavy-duty skid frames for large equipment, pre-assembled skid-mounted systems (pump skids, heat exchanger units), and anti-vibration integrated base frames with spring mounts, elastomeric pads, and inertia blocks.

Yes, we offer comprehensive Annual Maintenance Contracts (AMC) including structural inspection, bolt tightening, corrosion monitoring, coating inspection, vibration assessment, and anchor bolt verification. Customized AMC plans are structured for structural HVAC installations.

Common causes include improper design leading to vibration transmission, equipment misalignment, structural fatigue, anchor bolt failure, uneven load distribution, and premature equipment wear. We provide corrective services including structural crack repair, reinforcement welding, and alignment correction.

Our installation services include base frame levelling, anchor bolt installation, non-shrink grouting, equipment placement, shaft alignment verification, vibration pad placement, and torque tightening to ensure accurate mechanical performance.

We integrate inertia blocks, spring isolators, rubber pads, structural dampers, and anti-vibration mounts. This improves equipment lifespan, reduces noise transmission, and ensures stable equipment performance.

We execute fabrication as per IS structural standards with proper steel cutting, MIG/ARC welding, full penetration welds where required, weld quality inspection, dimensional verification, and surface finishing to prevent structural failure.

We provide surface cleaning, primer coating, epoxy coating, powder coating where applicable, and hot-dip galvanizing if required to ensure durability in industrial environments.

Yes, we provide retrofitting services including structural crack repair, reinforcement welding, corroded base replacement, anchor bolt correction, alignment correction, and skid strengthening to extend equipment foundation life.

Proper engineering accounts for static load, dynamic load, rotational imbalance forces, seismic considerations, thermal expansion, and anchor bolt pull-out resistance. Well-engineered base frames ensure stable performance, reduced vibration, accurate alignment, and long-term durability.
